| MOQ: | 500.0 Meter/Meters |
| Standard Packaging: | Flexible welding Cable The package is usually wooden drum or steel wooden drum or coil.also according to customer's requirement. |
| Supply Capacity: | 100 Kilometer/Kilometers per Month |
4x1.5mm² Rubber Flexible Welding Cable
Universal welding cable
Universal welding cables are designed to withstand severe weather conditions. Even if exposed to oil, acid, alkali, flame and moisture, our cables can work normally. These wires undergo rigorous quality testing under the supervision of qualified professionals. These have several standard and custom specifications
Flexible welding Cable Specification
| Nominal | Approx | Nominal | Nominal | Nominal | Nominal | Approx. | Approx. |
| Area | Conductor | Insulation | bedding | Steel Wire | Sheath | Overall | Weight |
| Diameter | thickness | thickness | dia. | thickness | Diameter | ||
| mm² | mm | mm | mm | mm | mm | mm | Kg/km |
| 4x1.5 | 1.6 | 0.7 | 1 | 0.9 | 1.8 | 15 | 415 |
| 4x2.5 | 2 | 0.7 | 1 | 0.9 | 1.8 | 17.5 | 490 |
| 4x4 | 2.6 | 0.7 | 1 | 0.9 | 1.8 | 19 | 600 |
| 4x6 | 3.1 | 0.7 | 1 | 0.9 | 1.8 | 20 | 730 |
| 4x10 | 4 | 0.7 | 1 | 1.25 | 1.8 | 23 | 970 |
| 4x16 | 5 | 0.7 | 1 | 1.6 | 1.8 | 26 | 1520 |
| 4x25 | 6.3 | 0.9 | 1 | 1.6 | 1.8 | 29 | 2010 |
| 4x35 | 7.4 | 0.9 | 1 | 1.6 | 1.9 | 31 | 2560 |
| 4x50 | 8.8 | 1 | 1 | 1.6 | 2.1 | 36 | 3350 |
Application scope:
It is suitable for the electric welding fixture for the wiring of the secondary side of the welding machine cable and the connecting cable, and the exchange rated voltage does not exceed 200 V DC and the pulse peak value of 400V. For single-core structure, multiple units consist of soft wire cutters. The outer conductive core wire is insulated with polyester film around the package, and the outer layer is made of a rubber insulation layer and a sheath as a protective layer.
Features
1) Using aluminum alloy as conductor can make the cable price much lower, but the performance is almost
Copper cable
2) Low resistance and low voltage;
3) The long-term working temperature is 65℃;
4) Good bending performance, can be moved and twisted frequently;
5) Rubber is the sheath material, used for welding cables, with good tear resistance and wear resistance;
Video
|
|
| MOQ: | 500.0 Meter/Meters |
| Standard Packaging: | Flexible welding Cable The package is usually wooden drum or steel wooden drum or coil.also according to customer's requirement. |
| Supply Capacity: | 100 Kilometer/Kilometers per Month |
4x1.5mm² Rubber Flexible Welding Cable
