What is a welding cable?
Welding cables are designed to be used in arc welders to power electrodes (a specially designed metal rod) to conduct electrical charges. The charge carried by the electrode is required to create an arc (heat source) between the electrode and the metal being welded.
Welding cables are made very durable and flexible. Arc welding requires someone to move the electrode in the workshop and along the joint to be welded, so it is essential to have a flexible welding cable that is easy to move. The high strand count and rubber insulation layer help increase the flexibility of the cable.
Durable cables are important in industrial environments. In industrial environments, scratches, cuts, spark burns, and oil and water exposure can quickly wear weaker cables.
Our welding cable is a highly flexible stranded wire 30 gauge bare copper conductor and insulated with high quality black EPDM. Use a paper separator to enhance peelability. In a circuit that does not exceed 600 volts, the maximum operating temperature of the conductor is 105°C. The minimum rated temperature is -50°C.
Flexible welding Cable Specification
Conductor Nominal Section (mm2) |
Conductive Core |
Thickness of Section Sheath (mm) |
Average Outer Diameter (mm2) |
20oC Conductor Resistance≤(Ω/km) |
Reference Weight(kg/km) |
Number/Diameter of Core(mm) |
Min |
Max |
YH |
YHF |
10 |
322/0.20 |
1.8 |
7.5 |
9.7 |
1.91 |
146 |
153.51 |
16 |
513/0.20 |
2 |
9.2 |
11.5 |
1.16 |
218.9 |
230.44 |
25 |
798/0.20 |
2 |
10.5 |
13 |
0.758 |
316.6 |
331.15 |
95 |
2997/0.20 |
2.6 |
17 |
22 |
0.198 |
1066.17 |
1102.97 |
120 |
1702/0.30 |
2.8 |
19 |
24 |
0.161 |
1348.25 |
1392.55 |
150 |
2135/0.30 |
3 |
21 |
27 |
0.129 |
1678.5 |
1698.72 |
Welding cable application field
Arc welding: For welding applications, two 10mm2 welding cables are required: one to connect the machine to the electrode, and the other to connect the machine to the workpiece to be welded. These two cables form a complete circuit.
Other uses: Welding cables are durable and flexible, and are mainly used for entertainment or stage lighting cables, lighting and sound systems, and communication vehicles. They can also be used as car battery cables, inverter cables, and can be a more economical alternative to suspension (or reel) cables on hoists and cranes.
FAQ
1. The time you can get the quotation after the sending the inquiry
In the working time, our sales manager will send quotation to your email box within 1 or 2 hours. On the contrast, we will send you email within 12 hours. Therefore, email is needed to let us know, then we can contact with you.
2. For Sample
We can provide you the sample for free, if you want to check the cable, you can ask the sales manager.
3.Payment
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight
4. what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement.
