Anti Oil Single Core 600V 0.20mm Flexible Welding Cable

Anti Oil Single Core 600V 0.20mm Flexible Welding Cable

Products - Flexible Welding Cable
  • High Light

    0.20mm Flexible Welding Cable

    ,

    600V Flexible Welding Cable

    ,

    Anti Oil Rubber Welding Cable

  • Insulation Material
    Rubber
  • Type
    Rubber Cable
  • Application
    Construction, Welding Machines
  • Conductor Material
    Copper/Aluminum
  • Jacket
    Rubber
  • Rated Voltage
    450/750V
  • Number Of Cores
    Single Core
  • Certificate
    ISO9001/CCC
  • Temperature Range
    -50°C~105°C
  • Number Of Cores/diameter (mm)
    1121 / 0.20 M
  • Place of Origin
    Henan, China
  • Brand Name
    HOLD-ONE
  • Certification
    ISO 9001, SGS
  • Model Number
    Flexible welding Cable
  • Minimum Order Quantity
    500.0 Meter/Meters
  • Packaging Details
    Flexible welding Cable The package is usually wooden drum or steel wooden drum or coil.also according to customer's requirement.
  • Supply Ability
    100 Kilometer/Kilometers per Month

Anti Oil Single Core 600V 0.20mm Flexible Welding Cable

  • Anti Oil Single Core 600V 0.20mm Flexible Welding Cable
Get Price Contact Now

1121 / 0.20 mm rubber Flexible Welding Cable



Welding cable:

Wires and cables, your way" provides a wide range of flexible copper welding cables at low prices and can be sold by foot, so you can get exactly what you need without wasting money. These cables are used by professional welders, Used for secondary withstand voltage welding leads and as a power source for welding tools and applications that do not require 600 volt AC.

All of our welding wire options have excellent flexibility and durability, and are as professional as the people who use them. We provide different cables



Flexible welding Cable Specification:



Conductor Nominal Section (mm2) Conductive Core Thickness of Section Sheath (mm) Average Outer Diameter (mm2) 20oC Conductor Resistance≤(Ω/km) Reference Weight(kg/km)
Number/Diameter of Core(mm) Min Max YH YHF
10 322/0.20 1.8 7.5 9.7 1.91 146 153.51
16 513/0.20 2 9.2 11.5 1.16 218.9 230.44
25 798/0.20 2 10.5 13 0.758 316.6 331.15
35 1121/0.20 2 11.5 14.5 0.536 426 439.87

Special function:

Comply with SAW J1127

Resistant to abrasion, cutting, tearing, ozone, flame, grease, oil, water, acid, diesel and gas

Order mark

Made in China

Rated 600V


FAQ



1. The time you can get the quotation after the sending the inquiry

In the working time, our sales manager will send quotation to your email box within 1 or 2 hours. On the contrast, we will send you email within 12 hours. Therefore, email is needed to let us know, then we can contact with you.

2. For Sample

We can provide you the sample for free, if you want to check the cable, you can ask the sales manager.

3.Payment

Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight

4. what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement.
