1.5mm2 single-core PVC insulated cable
product description
Annealed flexible copper conductor/PVC insulation/PVC sheath.
In the case where the risk of mechanical damage and mechanical stress is normal (for example, when the mechanical stress of the cable in the application field is low, and the risk of mechanical damage is low), ordinary flexible cords/flexible cords can be used in homes and businesses as well as Small and medium-sized equipment is normally used in light industrial sites.
Examples of equipment requiring common load cables include vacuum cleaners, toasters, washing machines, refrigerators, clothes dryers, and televisions.
Technical Parameters:
Cross Section | Conductor | Conductor Screen | Insulation | Insulation Screen | Metallic Screen | Inner Sheath | Armour | Screen Layer No. | Outer Sheath | Overall Diameter | Copper Cable | Aluminum Cable |
mm2 | mm | mm | mm | mm | mm | mm | mm | mm | mm | kg/km | kg/km | |
50 | 8.4 | 0.8 | 10.5 | 0.8 | 0.1 | 2.0 | 0.8 | 2 | 4 | 86 | 8906 | 7997 |
70 | 10 | 0.8 | 10.5 | 0.8 | 0.1 | 2.1 | 0.8 | 2 | 4 | 90 | 9944 | 8671 |
95 | 11.5 | 0.8 | 10.5 | 0.8 | 0.1 | 2.1 | 0.8 | 2 | 4 | 94 | 11112 | 9375 |
120 | 13 | 0.8 | 10.5 | 0.8 | 0.1 | 2.2 | 0.8 | 2 | 4 | 97 | 12253 | 10059 |
150 | 14.5 | 0.8 | 10.5 | 0.8 | 0.1 | 2.3 | 0.8 | 2 | 4 | 101 | 13557 | 10800 |
185 | 16.2 | 0.8 | 10.5 | 0.8 | 0.1 | 2.3 | 0.8 | 2 | 4 | 105 | 15059 | 11645 |
240 | 18.4 | 0.8 | 10.5 | 0.8 | 0.1 | 2.4 | 0.8 | 2 | 4 | 110 | 17249 | 12837 |
300 | 20.5 | 0.8 | 10.5 | 0.8 | 0.1 | 2.5 | 0.8 | 2 | 5 | 115 | 19603 | 14061 |
400 | 23.5 | 0.8 | 10.5 | 0.8 | 0.1 | 2.6 | 0.8 | 2 | 5 | 122 | 23151 | 15874 |
500 | 26.5 | 0.8 | 10.5 | 0.8 | 0.1 | 2.8 | 0.8 | 2 | 5 | 129 | 27045 | 17807 |
The main purpose
Cross-linked polyethylene (XLPE) cables have excellent electrical and physical properties and are the best cables for transmission and distribution lines. The advantages of these cables are simple structure and light weight; in addition to excellent electrical, thermal, mechanical and chemical resistance, they also have the convenience of application. It can also be placed along the route without being restricted by height differences.
