Flexible Electrical Cable H07V-U Solid Bare Copper Conductor For Power

Product Details:
Brand Name: HOLD-ONE
Payment & Shipping Terms:
Minimum Order Quantity: 100m
Price: USD 0.87-2.66/M
Packaging Details: Wooden drum
Delivery Time: 7 Days after received deposit
Payment Terms: L/C, T/T
  • Detail Information
  • Product Description

Detail Information

Conductor Type:: Flexible Sheath Color: Optional
Conductor Material: Pure Copper Application: Industrial,Household
Product Name: Flexible Electrical Cable Insulation Material: PVC
High Light:

flexible cable wire

,

flexible power cable

Product Description

low voltage flame retardant power cable



Flexible Electrical Cable



The product issuitable for power and lighting circuits and building wiring. The cable is intended for use insemi-flush exposed conduits andembedded conduits as well as in closedinstallation ducts,and is ideal for the internal wiring of appliances.



Brief construction



1) Conductor: Copper ,Stranded

2) Insulation: PVC

3) Sheath:PVC

4) Other special characteristics: Design and manufacture according to the requirements of customers.



Flexible Electrical Cable Application


Applicable to the cables and wires of rated yolatage 450/750V and less than 450/750V AC for power
plant, household electrical applance,insurment and telecommunication equipment.



Service performance



1) Long-term working temperature: not be higher than 70°C

2) When laying the cable, the ambient temperature should not lower than 0°C

3) Minimum bending radius: Bending radius≥4D as cable overall diameter≤25mm; Bending radius≥6D as cable overall diameter>25mm.


Number of cores Normal area
(mm²)
Structure
(m)
Approx overall dia
(mm)
2 cores 0.5 28/0.15 5.2
0.75 24/0.2 6.4
1 32/0.2 6.6
1.5 30/0.25 7.6
2.5 49/0.25 9.4
3 cores 0.5 28/0.15 5.5
0.75 24/0.2 7.2
1 32/0.2 7.2
1.5 30/0.25 8.5
2.5 49/0.25 10
4 56/0.3 11.7
6 84/0.3 13
4 cores 1 32/0.2 8
1.5 30/0.25 9.2
2.5 49/0.25 11
4 56/0.3 12.8
6 84/0.3 15.4
10 126/0.32 18.8
5 core 1.5 30/0.25 10.7
2.5 49/0.25 12.8
4 56/0.3 14.5
6 84/0.3 16.4
10 126/0.32 21.1
16 126/0.40 25.4


We are a manufacture in this filed for many years, we can offer our customers cables with good quality and price.

We Sincerely welcome customers at home and abroad to negotiate and cooperate with us !!!
