Electric Twin Flat Flexible Electrical Cable For Static Outdoor Application

Electric Twin Flat Flexible Electrical Cable For Static Outdoor Application

  • High Light

    flexible cable wire

    ,

    flexible power cable

  • Sheath Color
    Optional
  • Conductor Material
    Pure Copper
  • Conductor Type
    Flexible
  • Application
    Industrial,Household
  • Insulation Material
    PVC
  • Product Name
    Flexible Electrical Cable
  • Brand Name
    HOLD-ONE
  • Minimum Order Quantity
    100m
  • Price
    USD 0.87-2.66/M
  • Packaging Details
    Wooden drum
  • Delivery Time
    7 Days after received deposit
  • Payment Terms
    L/C, T/T

Electric Twin Flat Flexible Electrical Cable For Static Outdoor Application

low voltage flame retardant power cable



Flexible Electrical Cable



--> Distribution and signal power cable for static outdoor application (with protection against direct UV- irradiation);

--> In ground, in water, within facilities, in cable canals, in concrete,etc;

--> Used in electric power plants, transformer stations, industrial plants, metropolitan networks and in other electric plants, same as for connection of signalling devices in industry, traffic and similar.



Brief construction



1) Conductor: Copper ,Stranded

2) Insulation: PVC

3) Sheath:PVC

4) Other special characteristics: Design and manufacture according to the requirements of customers.



Flexible Electrical Cable Application


Applicable to the cables and wires of rated yolatage 450/750V and less than 450/750V AC for power
plant, household electrical applance,insurment and telecommunication equipment.



Service performance



1) Long-term working temperature: not be higher than 70°C

2) When laying the cable, the ambient temperature should not lower than 0°C

3) Minimum bending radius: Bending radius≥4D as cable overall diameter≤25mm; Bending radius≥6D as cable overall diameter>25mm.


Number of cores Normal area
(mm²)
Structure
(m)
Approx overall dia
(mm)
2 cores 0.5 28/0.15 5.2
0.75 24/0.2 6.4
1 32/0.2 6.6
1.5 30/0.25 7.6
2.5 49/0.25 9.4
3 cores 0.5 28/0.15 5.5
0.75 24/0.2 7.2
1 32/0.2 7.2
1.5 30/0.25 8.5
2.5 49/0.25 10
4 56/0.3 11.7
6 84/0.3 13
4 cores 1 32/0.2 8
1.5 30/0.25 9.2
2.5 49/0.25 11
4 56/0.3 12.8
6 84/0.3 15.4
10 126/0.32 18.8
5 core 1.5 30/0.25 10.7
2.5 49/0.25 12.8
4 56/0.3 14.5
6 84/0.3 16.4
10 126/0.32 21.1
16 126/0.40 25.4


We are a manufacture in this filed for many years, we can offer our customers cables with good quality and price.

We Sincerely welcome customers at home and abroad to negotiate and cooperate with us !!!
