Product Details:
|
|
Place of Origin: | China |
---|---|
Brand Name: | HOLD-ONE |
Certification: | CE/IEC/KEMA/VDE |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | Negotiable |
Price: | Negotiable |
Packaging Details: | Iron-wooden Drum or Whole Wooden Drum |
Delivery Time: | 8-15 days |
Payment Terms: | L/C, T/T |
Supply Ability: | 100km per Month |
Detail Information |
|||
Name: | Copper Conductor Cable | Conductor Material:: | Copper |
---|---|---|---|
Standard: | IEC 60502-1 | Outer Sheath:: | PVC |
Color: | Customized | Type: | XLPE Underground Cable |
High Light: | Low Voltage XLPE Underground Cable,1KV XLPE Underground Cable,CE xlpe insulated power cable |
Product Description
Low Voltage 0.6/1KV XLPE Insulated Power Cable
XLPE insulated power cable
The cross-linked polyethylene insulated power cable is a copper core AC 1kv-35kv power cable, which is mainly used for power transmission between equipment and between transmission and distribution stations. It adopts the national grid and has the characteristics of complete specifications and diverse structures. Among them, WDZ is a low-smoke, halogen-free material with anti-aging, tear-resistant, low-smoke, halogen-free and flame retardant properties, and can maintain its excellent electrical and mechanical properties in complex environments. More reliable performance
Physical and Electrical Characteristics
No.cores x | Insulation | Sheath | Outer Ø | weight | Current ratings in air 30℃ | Current ratings buried 20℃ | |
cross-sec. | thickness | thickness | approx. | approx. | |||
Nominal | |||||||
Phase | Neutral | value | |||||
mm² | mm | mm | mm | mm | kg / km | A | A |
3×4+1×2.5 | 0.7 | 0.7 | 1.8 | 12.7 | 277 | 37 | 47 |
3×6+1×4 | 0.7 | 0.7 | 1.8 | 13.9 | 363 | 47 | 60 |
3×10+1×6 | 0.7 | 0.7 | 1.8 | 16.1 | 527 | 64 | 81 |
3×16+1×10 | 0.7 | 0.7 | 1.8 | 18.6 | 766 | 85 | 106 |
3×25+1×16 | 0.9 | 0.7 | 1.8 | 22.2 | 1140 | 113 | 137 |
3×35+1×16 | 0.9 | 0.7 | 1.8 | 24.6 | 1475 | 139 |
164 |
Construction
Conductor: Copper or Aluminum
Conductor Shape: Circular Stranded or Compacted Circular Stranded
Appearance Shape: Circular
Insulation: XLPE
Armour Type: STA(Steel Tape Armoured), SWA(Steel Wire Armoured), AWA(Aluminum Wire Armoured)
Sheath Material: PVC or Polyethylene
