Single Core 35mm XLPE Shielded Outdoor Armored Cable

Single Core 35mm XLPE Shielded Outdoor Armored Cable

Products - XLPE Insulated Cable
  • High Light

    XLPE Shielded Outdoor Armored Cable

    ,

    XLPE Underground Copper Conductor Cable

    ,

    35mm Outdoor Armored Cable

  • Name
    Copper Conductor Cable
  • Conductor Material
    Copper
  • Standard
    IEC 60502-1
  • Outer Sheath
    PVC
  • Color
    Customized
  • Type
    XLPE Underground Cable
  • Place of Origin
    China
  • Brand Name
    HOLD-ONE
  • Certification
    CE/IEC/KEMA/VDE
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    Iron-wooden Drum or Whole Wooden Drum
  • Delivery Time
    8-15 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    100km per Month

Single Core 35mm XLPE Shielded Outdoor Armored Cable

  • Single Core 35mm XLPE Shielded Outdoor Armored Cable
  • Single Core 35mm XLPE Shielded Outdoor Armored Cable
Get Price Contact Now

XLPE shielded outdoor armored cable



Single core 35mm armored cable

Single-core 35mm armored cable is a component that fixes one or more XLPE insulated electrical conductors with ordinary PVC sheaths. This component is used to transmit low-voltage electric power. LV XLPE XLPE power cables can be set up as permanent circuits in buildings, buried underground, overhead or bare.


Physical and Electrical Characteristics



No.cores x Insulation Sheath Outer Ø weight Current ratings in air 30℃ Current ratings buried 20℃
cross-sec. thickness thickness approx. approx.
  Nominal
Phase Neutral value
mm² mm mm mm mm kg / km A A
3×4+1×2.5 0.7 0.7 1.8 12.7 277 37 47
3×6+1×4 0.7 0.7 1.8 13.9 363 47 60
3×10+1×6 0.7 0.7 1.8 16.1 527 64 81
3×16+1×10 0.7 0.7 1.8 18.6 766 85 106
3×25+1×16 0.9 0.7 1.8 22.2 1140 113 137
3×35+1×16 0.9 0.7 1.8 24.6 1475 139

164





Application

XLPE insulated power cables are used as power transmission lines. The general conditions are as follows:

Mainly used to transmit power or as a control cable.
The general working temperature in wet or dry environment is as high as 90°C (130°C emergency and 250°C short circuit).
The voltage rate is 600/1Kv.
Suitable for overhead (air) installations, main power lines or auxiliary power lines buried in the ground or in dust.
Cable ducts, cable trays, cable ladders, in tunnels or conduits, and in switch cabinets and other complex operating environments.
When it is necessary to isolate electromagnetic effects, anti-interference, anti-interference and increase strength, it can work perfectly after metal sheath (metal, especially aluminum cladding) or metal wire armor (especially steel wire armor-SWA).

Feature of product


Excellent electrical and physical properties-less electrical transmission loss and energy saving.

The ability to carry large current-higher operating temperature.

Higher strength and stability-resistance to thermal deformation, stress cracking and thermal aging.

Easy to install-no line layout restrictions, no terrain or height restrictions.

Maintenance-free-up to 60 years of service life.

Our advantage

Only use high-quality XLPE insulation materials.

Mass production provides you with competitive prices.

Free samples and OEM are provided.



Single Core 35mm XLPE Shielded Outdoor Armored Cable 0



Standard



0.6/1KV XLPE insulated power cable meets or exceeds the following specifications:



IEC 60332-1 is a test for electrical and optical cables under fire conditions.

IEC 60502-1 insulated and extruded power cables and accessories, rated voltages of 1 kV and 3 kV.

IEC 60754 tests the gas generated during the combustion of cable materials.

IEC 61034 is a measurement of the smoke density of a burning cable under specified conditions.

BS 7870-3 low and medium voltage polymer insulated cables for power distribution and power generation.

DIN VDE0276-603 Power Cables-Part 603: Distribution cables with a rated voltage of 0.6 / 1 kV.

ANSI/NEMA WC 70-2009/ICEAS-95-658 A power cable with a rated power of 2000 volts or less, used to distribute electrical energy.

AS/NZS 4026: 2008 Cable-Standards Australia for underground residential power distribution system.

AS/NZS 4961: 2003 cables-polymer insulation-used in power distribution and service applications.

AS/NZS 5000.1: 2005 cable-polymer insulation-suitable for working voltages of 0.6/1 (1.2) kV and below.

Other equivalent standards for PVC insulated power cables.
