XLPE shielded outdoor armored cable
Applications:
|
Public service Railway stations, road & rail tunnels, public lighting, car parks, public service buildings. |
|
Property & personal safety Shopping malls, airports, underground rail systems, schools, hospitals, hotels, theatres, churches. |
|
High temperature situation Foundries, power stations, boiler houses, iron & steel industries, marine & ship buildings. |
|
Potentially explosive area Refineries, chemical plants, oil & gas production, filling stations, processing plants, garages. |
|
Hygiene situation Food & drink processing, pharmaceutical works, hospitals, kitchens, refrigeration plants. |
|
General installation Power distribution & sub circuits, fire alarms & emergency, lifts & escalators lighting, lighting & power. |
Description:
|
Fire resistant Will neither burn or support combustion. Comply with the requirements of IEC 60331 and BS 6387. |
|
High operation temperature Continuous operating temperature up to 250 °C, and for short periods up to approaching the melting point of copper 1083 °C. |
|
Inherent flameproof barrier With a non-flammable sheath the high compacted insulation will resist the transmission of vapors, gases or flames. |
|
High mechanical strength Really robust and can withstand a considerable amount of stresses such as, twisting, bending and flattening. |
|
Pliable Fully annealed and extremely ductile and easily manipulated to follow existing wiring routes and irregular shapes. |
|
Non-ageing, Integral earth continuity, Small overall diameter Waterproof, Corrosion resistant, Radiation resistant Excellent electric shielding, Easy installation, Long service life |
Physical and Electrical Characteristics
| No.cores x | Insulation | Sheath | Outer Ø | weight | Current ratings in air 30℃ | Current ratings buried 20℃ | |
| cross-sec. | thickness | thickness | approx. | approx. | |||
| Nominal | |||||||
| Phase | Neutral | value | |||||
| mm² | mm | mm | mm | mm | kg / km | A | A |
| 3×4+1×2.5 | 0.7 | 0.7 | 1.8 | 12.7 | 277 | 37 | 47 |
| 3×6+1×4 | 0.7 | 0.7 | 1.8 | 13.9 | 363 | 47 | 60 |
| 3×10+1×6 | 0.7 | 0.7 | 1.8 | 16.1 | 527 | 64 | 81 |
| 3×16+1×10 | 0.7 | 0.7 | 1.8 | 18.6 | 766 | 85 | 106 |
| 3×25+1×16 | 0.9 | 0.7 | 1.8 | 22.2 | 1140 | 113 | 137 |
| 3×35+1×16 | 0.9 | 0.7 | 1.8 | 24.6 | 1475 | 139 |
164 |
Constructions:
Core 1 2 3 4 5 3+1 3+2 4+1 Cores
Working life <25years
Type of conductor copper,class 5
Material of conductor fine strands of oxygen-free Copper
Material of insulation mineral compound (MgO)
Color of core insulation Red/White/Blue/Black/Green/Yellow(Optional)
Material of Sheath low smorke halogen free Polyolefine(LSZH/LSOH PO)
Voltage 600~1000 VOLTS
Advantage Down to depths 500 mtrs
Section 0.25mm2~95.00mm2/AWG1~AWG14
Minimum bending radius Cable installtion allowed bending radius should no less than 6 times of cable wideth
Flame resistance pass GB/T18380.1-2001 test and GB5023.6-2012
Isolated sheath Aluminum(AL)
Our products are sold all over the world, you can rest assured.
