ASTM 4 Core 35mm2 XLPE Insulated Armored Power Cable

ASTM 4 Core 35mm2 XLPE Insulated Armored Power Cable

  • High Light

    XLPE Insulated Armored Power Cable

    ,

    35mm2 Armored Power Cable

    ,

    4 Core XLPE Insulated Cable

  • Rated Voltage
    0.6/1kV
  • Cross Section Area
    240 Sqmm
  • Outer Sheath Color
    Black Or As Per Request
  • Core Mark
    Number Or Color Strip
  • Manufacturer
    Top 3 China Cable Manufacturer
  • Number Of Cores
    4
  • Place of Origin
    China
  • Brand Name
    HOLD-ONE
  • Certification
    CE/IEC/KEMA/VDE
  • Minimum Order Quantity
    500 m
  • Packaging Details
    Iron-wooden Drum
  • Delivery Time
    14 days
  • Payment Terms
    L/C, T/T, Western Union, MoneyGram,
  • Supply Ability
    100km per Month

ASTM 4 Core 35mm2 XLPE Insulated Armored Power Cable

Copper Price 4-Core 35mm2 XLPE Insulated Armored Power Cable



XLPE insulated PVC sheathed cable

Specification

1. Conductor: copper or aluminum.
2. Provide armored and non-armored power cords.
3. Rated voltage: 0.6 / 1kV 3.6 / 6kV 6 / 10kV 8.7 / 15kV 26 / 35kV.
4. PVC or XLPE sheath.
5. Cable core number: one core (single core), two cores (double core), three cores,
Four cores (four cores with equal cross-sectional area or three cores with equal cross-sectional area and one neutral core with smaller cross-sectional area),
Five cores (five cores of equal area or three cores of equal cross section and two neutral cores of smaller cross section).
6. Standard: IEC 60502.IEC, BS, DIN, ASTM, CSA, NFC, AS, GOST, etc. Or other special features according to customer requirements.


Physical and Electrical Characteristics



No.cores x

Insulation

Sheath

Outer Ø

weight

Current ratings in air 30℃

Current ratings buried 20℃

cross-sec.

thickness

thickness

approx.

approx.



Nominal

Phase

Neutral

value

mm²

mm

mm

mm

mm

kg / km

A

A

3×4+1×2.5

0.7

0.7

1.8

12.7

277

37

47

3×6+1×4

0.7

0.7

1.8

13.9

363

47

60

3×10+1×6

0.7

0.7

1.8

16.1

527

64

81

3×16+1×10

0.7

0.7

1.8

18.6

766

85

106

3×25+1×16

0.9

0.7

1.8

22.2

1140

113

137

3×35+1×16

0.9

0.7

1.8

24.6

1475

139

164



Characteristics of xlpe power cable

1. The maximum insulation temperature is the long-term working temperature of PVC insulated cable is 70°C, and XLPE is 90°C
2. The installation temperature of the cable should not be lower than 0°C
3. The maximum temperature of short circuit: PVC does not exceed 160°C, XLPE 250°C, does not exceed 5 seconds
4. Cable with allowable bending radius: not less than 10 D times (D: outer diameter of the cable) 5.
Perfect chemical stability, acid, alkali, grease and organic solvent resistance, and flame retardant.

5. Structural parameters of XLPE insulated power cable with rated voltage 0.6/1KV
ASTM 4 Core 35mm2 XLPE Insulated Armored Power Cable 0
