3-Core Copper Core Medium Voltage Armored XLPE Insulated Cable
1. XLPE cable standard:
According to GB12706 (equivalent to IEC60502), it can also be manufactured according to ASTM, BS, DIN and AS/NZS standards or other standards.
2. Rated voltage of XLPE cable:
0.6 / 1KV 6 / 10KV; 8.7 / 15KV; 12 / 20KV; 18 / 20KV; 21 / 35KV; 6 / 35KV
3. The structure of XLPE cable:
Conductor: copper or aluminum
Insulation: XLPE
Inner sheath: PVC or PE
Armour: galvanized steel strip, galvanized steel wire
Outer sheath: PVC or PE
No. Number of cable cross-sections: 1 core (single core), 2 cores (double core), 3 cores, 4 cores (4 cores with equal cross-sectional area or 3 cores with equal cross-sectional area + 1 neutral core with small cross-sectional area), 5 Core (5 3 equal-cross-sectional area cores + 2 small-area neutral cores or 4 equal cross-sectional areas + 1 small-area neutral core. We provide armored and unarmored types for the above cables.
It can also be made according to customer requirements.
4. Features of XLPE cable:
a. The maximum long-term working temperature of XLPE insulated cables is 90°C
b. The installation temperature of the cable should not be lower than 0°C
c. The maximum short-circuit temperature does not exceed 250°C and does not exceed 5 seconds
d. Without sufficient mechanical pulling force, it cannot be laid without restriction, single-core cables cannot be laid in iron pipes or the cables can be fixed with coiled iron tools
5. Description & Application of XLPE Cable:
| TYPE |
NAME |
Main Application |
| CU core |
AL core |
|
|
| YJV/YJY |
YJLV/YJLY |
XLPE insulated,PVC/PE sheathed power cable |
For laying indoor ,tunnel,canal and underground.Unable to bear external mechanical forces,but bear the traction force during laid |
| YJV22/YJV23 |
YJLV22/YJLV23 |
XLPE insulated,steel tape armored,PVC/PE sheathed power cable |
For laying indoor ,tunnel,canal and underground.Able to bear external mechanical forces,but unable to bear large pulling force |
| YJV32/YJV33 |
YJLV32/YJLV33 |
XLPE insulated,thin steel wire armored,PVC/PE sheathed power cable |
For laying in shaft,water underground will large difference of level.Able to bear external mechanical forces and moderate pulling force |
| YJV42/YJV43 |
YJLV42/YJLV43 |
XLPE insulated,thick steel wire armored,PVC/PE sheathed power cable |
For laying in water and seabed.Able to bear positive pressure and pulling force |
6. Advantages:
One kind. Excellent electrical and mechanical properties
b. Best resistance to chemical corrosion and thermal aging, environmental stress and flame retardancy
C. Simple structure, easy to use
d. cut costs
