Qingdao Yilan Cable Co., Ltd.

Fire Resistance Direct Burial Power Cable , High Voltage Power Cables

Product Details:
Place of Origin: China
Brand Name: HOLD-ONE
Certification: CE/IEC/KEMA/VDE
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Iron-wooden Drum or Whole Wooden Drum
Delivery Time: 8-15 days
Payment Terms: L/C, T/T
Supply Ability: 100km per Month
  • Detail Information
  • Product Description

Detail Information

Name: Direct Burial Power Cable Feature: Fire Resistance
Core: Single Core Outer Sheath:: PVC
Color: Customized Usage: High Voltage Power Cables
High Light:

xlpe power cable

,

cross linked polyethylene cable

Product Description

Fire Resistance Direct Burial Power Cable , High Voltage Power Cables



Quick details

-------------------------------------------------------

Nominal cross section:2X10 mm2

Overall diameter Ø approx:15.2mm

Net weight approx: 362 kg/km

Conductor DC resistant at 20°C:1.83 Ω/km

Electrical characteristics

-------------------------------------------------------

Rated voltage Uo/U (Um): 600 / 1000 V

Maximum current rating air 30°C:84 A

Maximum current rating buried 20°C: 115 A

Maximum DC resistance, conductor 20°C: 1.83Ω / km

Test voltage: 4000 V

Dimensional characteristics

-------------------------------------------------------

Nominal cross-section: 10 mm2

No of Conductors: single 2 Core

Insulation thickness: 0.7mm

sheath thickness nominal value:1.8 mm

Max overall diameter Ø: 15.2 mm

Approximate weight:362kg/km



Usage characteristics

-------------------------------------------------------

Maximum operating temperature: 90 °C

Short circuit temperature: +250°C (short circuit duration max. 5 s)

during installation up to -5°C

Temperature range: - 20 to + 90 °C

Minimum bending radius:15 x cable Ø



Standards

-------------------------------------------------------

International: IEC 60502-1
National:GB/ T 12706.1-2008

Construction characteristics

-------------------------------------------------------
1. Conductor
– Bare copper conductor, Class 2 to IEC 60228

–​ For smaller sizes, a solid round conductor, Class 1
2. Insulation: XLPE Compound

3. Filler: PP filler
4. Outer Sheath :PVC Compound
5. Sheath colour :Black

Note:

when required for a particular application, other colors are available.

RECOMMENDED ORDERING PARAMETERS

-------------------------------------------------------

For prompt quotation / supplies please make sure your inquiries and your orders are
securing the following data :

1 - International or Special Standard. (Alternatively, the precise usage of the cable.)
2 - Rated voltage.
3 - Copper or Aluminium conductors.
4 - Size of each conductor.
5 - Insulation material : XLPE or others.
6 - Number and identification of conductors.
7 - Other requirements.
8 - Packing.
9 - Required delivery time.
10 - Required validity.
