2 Core Flat / Round 8 Awg Solar Wire , 6mm2 Solar Cable Weather Resistant

Product Details:
Place of Origin: China
Brand Name: HOLD-ONE
Certification: TUV,ISO,CE,IEC
Payment & Shipping Terms:
Minimum Order Quantity: 3000meter
Price: US$0.97 per meter
Packaging Details: Wooden drums
Delivery Time: 10 work days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 25000Kilometer per Month
Contact Now
  • Detail Information
  • Product Description

Detail Information
Model Name: PV 2x4mm2 Conductor Type: Tinned Copper
Size: 2x4 Sq.mm Nos.of Core: Twin Cores
Insulation Color: Pantone Color Warranty: 2 Years
High Light:

solar pv wire

,

solar cable wire

Product Description

2 Core Flat / Round Solar Cable Wire , Solar Panel Cable Pantone Insulation Color



Application



Especially for the connection between Solar power generation device connector and connection of inverter, Under the condition of different climate outdoor installation, and can adapt to the dry and wet indoor working environment



Construction



1. Core Conductor: Tinned annealed copper (stranded core)

2. Popular sizes: 2core x2.5/4.0/6.0/10.0/16.0/25.0/35.0mm²

3. Cable conductor: stranded tinned annealed copper

4. Insulation: electron-beam cross-linked Polyolefin(XLPE)

5. Jacket:XLPE/ PE (black, red)

6. Other specs:

a)Temperature rating: -40C up to +120C

b). Fire performance: IEC 60332-1, UL1581 VW-1

c). Approval: TUV Rheinland 2PfG 1169 1.5mm² to 50mm²

d). High resistance against hear, cold, abrasion, UV, Ozone and hydrolyes. Halogen free, flame ratardant

e). Voltage suitable: 600-1000V



Advantage



With high resistance against heat, cold, ozone, UV, oil, microorganism, abrasion, acid & alkaline; Flame free, flexible, easy to strip, extremely mechanical robust, long lifespan etc



We are a manufacture in this filed for many years, we can offer our customers cables with good quality and price.

We Sincerely welcome customers at home and abroad to negotiate and cooperate with us !!!
