Industrial Prefabricated Branch Cable IEC60502 For Power Transmission

Industrial Prefabricated Branch Cable IEC60502 For Power Transmission

  • High Light

    prefab cables

    ,

    electric power cable

  • Color Of Insulation
    Any Colour
  • Sample
    Free
  • Nominal Area Of Conductor
    6mm2 To 630mm2
  • Warranty
    2 Years
  • Conductor Type
    Stranded Copper Conductor(class2)
  • Standard
    IEC 60502-1,IEC60228
  • Main Market
    Asia,Midldle-East,African,
  • Place of Origin
    China
  • Brand Name
    HOLD-ONE
  • Certification
    CE/KEMA/CCC/TUV
  • Minimum Order Quantity
    500m
  • Price
    USD 34.56-48.78/m
  • Packaging Details
    wooden drum ,drum size:1.25x1.25x0.75m, 20 ft container can load 12 packages
  • Delivery Time
    10-15 days
  • Payment Terms
    L/C, T/T, L/C, T/T, Western Union
  • Supply Ability
    100KM/day

Industrial Prefabricated Branch Cable IEC60502 For Power Transmission

Single Core Prefabricated Branch Cable Flame Resistant Main cable 1 x 185 mm2





Prefab branch cable with rated voltage 0.6/1KVis a new Kind of low voltage distribution products. The prefab style can decrease the labor intensity greatly, shorten work time, and reduce cost greatly.



Custom Professional Prefabricated Branch Cable 3.5KV / 5min Test Voltage



1. Rated power-frequency voltage U0/U: 450/750V, 300/500V and 300/300V.



2. Maximum permitted operating temperature of conductor is 60°C.



3. Permitted lowest working temperature is -35°C.



4. Cables can be used at places contaminated by mineral oil and fuel oil.



5. D more than 25mm



The minimum bending radius is over 6 times of cable diameter.



D not less than 25mm



Brief introduction


Prefab branch cable is a new kind of low voltage distribution products, the prefab style can decrease the labor intensity greatly, shorten worktime, reduce cost greatly. The products is widely used at mid and high building highway, bridges, channels, high level workshop etc with its super performance.



Application


This cable is used for urban networks. It can be installed aerially, in conduit, on open trays and in underground ducts.


Construction


Plain annealed copper, XLPE insulation, unarmoured or aluminium wires armoured, PVC sheathed cable



Main technical performance:
Ac voltage test: (put it in water for 1 hour) : 3.5kv /5min.
Dc resistance test: according to iec 60502-1997 standard

Insulation resistance test: 20 ℃ when meet not less than 200 m Ω insulation resistance
125 times thermal cycling: tapping temperature is not more than 70 ℃
Conductor breaking force: not less than 80% of the main cable



We are a manufacture in this filed for many years, we can offer our customers cables with good quality and price.

We Sincerely welcome customers at home and abroad to negotiate and cooperate with us !!!
