Prefabricated Branch XLPE Copper Cable , PVC Insulated Cable 20 X OD Bending Radius

Prefabricated Branch XLPE Copper Cable , PVC Insulated Cable 20 X OD Bending Radius

  • High Light

    low voltage power cable

    ,

    electric power cable

  • Color Of Insulation
    Grey ,Black Or According To Customer's Requirment
  • Bending Radius
    20 XO.D
  • Nominal Area Of Conductor
    6mm2 To 1200mm2
  • Hoisting Tool
    Optional
  • Conductor Type
    Stranded Copper Conductor(class2)
  • Standard
    IEC 60502-1,IEC60228
  • Main Market
    Asia,Midldle-East,African,
  • Place of Origin
    China
  • Brand Name
    HOLD-ONE
  • Certification
    CE/KEMA/CCC/TUV
  • Minimum Order Quantity
    500m
  • Price
    USD 4.56-8.78/m
  • Packaging Details
    wooden drum ,drum size:1.25x1.25x0.75m, 20 ft container can load 12 packages
  • Delivery Time
    10-15 days
  • Payment Terms
    L/C, T/T, L/C, T/T, Western Union
  • Supply Ability
    100KM/day

Prefabricated Branch XLPE Copper Cable , PVC Insulated Cable 20 X OD Bending Radius

Prefabricated Branch XLPE / PVC Insulated Cables 20 x OD Bending Radius





Main Manufacturing Procedure



1, Copper wire drawing and annealing.



2, Copper wire stranding .



3, PVC insulation extruding.



4, Cores Twisting.



5, Outer sheath extruding and labeling



6, Spooling



Brief introduction


Prefab branch cable is a new kind of low voltage distribution products, the prefab style can decrease the labor intensity greatly, shorten worktime, reduce cost greatly. The products is widely used at mid and high building highway, bridges, channels, high level workshop etc with its super performance.



Application


This cable is used for urban networks. It can be installed aerially, in conduit, on open trays and in underground ducts.


Construction


Plain annealed copper, XLPE insulation, unarmoured or aluminium wires armoured, PVC sheathed cable



Main technical performance:
Ac voltage test: (put it in water for 1 hour) : 3.5kv /5min.
Dc resistance test: according to iec 60502-1997 standard

Insulation resistance test: 20 ℃ when meet not less than 200 m Ω insulation resistance
125 times thermal cycling: tapping temperature is not more than 70 ℃
Conductor breaking force: not less than 80% of the main cable



We are a manufacture in this filed for many years, we can offer our customers cables with good quality and price.

We Sincerely welcome customers at home and abroad to negotiate and cooperate with us !!!
