Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | HOLD-ONE |
| Certification: | CE/IEC/KEMA/VDE |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | Iron-wooden Drum or Whole Wooden Drum |
| Delivery Time: | 8-15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100km per Month |
|
Detail Information |
|||
| Name: | Copper Conductor Cable | Conductor Material:: | Copper |
|---|---|---|---|
| Standard: | IEC 60502-1 | Outer Sheath:: | PVC |
| Color: | Customized | Type: | XLPE Underground Cable |
| High Light: | Three Core XLPE Insulated Cable,1000V XLPE Insulated Cable,Copper Conductor XLPE Underground Cable |
||
Product Description
600/1000V Three-Phase And Three-Core XLPE Insulated Cables
XLPE cable
This cable is used in applications that require electromagnetic compatibility (EMC) to power the motor from a variable speed controller in a fixed installation. The cable can be placed unenclosed, enclosed in a conduit, installed on a bracket or in an underground pipeline, and is suitable for variable speed drive equipment or other applications that require shielded cables.
Use ordinary annealed grade 2 or grade 5 copper conductors, X-90 insulation, 5V-90 bedding, copper tape shielding, unarmored or galvanized steel wire armor, nylon inner sheath, 5V-90 sheath
Physical and Electrical Characteristics
| No.cores x | Insulation | Sheath | Outer Ø | weight | Current ratings in air 30℃ | Current ratings buried 20℃ | |
| cross-sec. | thickness | thickness | approx. | approx. | |||
| Nominal | |||||||
| Phase | Neutral | value | |||||
| mm² | mm | mm | mm | mm | kg / km | A | A |
| 3×4+1×2.5 | 0.7 | 0.7 | 1.8 | 12.7 | 277 | 37 | 47 |
| 3×6+1×4 | 0.7 | 0.7 | 1.8 | 13.9 | 363 | 47 | 60 |
| 3×10+1×6 | 0.7 | 0.7 | 1.8 | 16.1 | 527 | 64 | 81 |
| 3×16+1×10 | 0.7 | 0.7 | 1.8 | 18.6 | 766 | 85 | 106 |
| 3×25+1×16 | 0.9 | 0.7 | 1.8 | 22.2 | 1140 | 113 | 137 |
| 3×35+1×16 | 0.9 | 0.7 | 1.8 | 24.6 | 1475 | 139 |
164 |
Application
Used as a distribution and transmission line with a rated voltage of 0.6/1kV.
Suitable for burying in the ground, laying wells and underwater. Able to withstand certain shaft tension.
International standards: IEC 60502-1, IEC 60228;
Requirements of other standards such as ASTM BS, DIN and ICEA
Technical data
Rated voltage: 0.6 / 1kV
Maximum conductor temperature: under normal (90 O C), emergency (130 O C) or short circuit conditions not exceeding 5 s (250 C).
Minimum ambient temperature. 0 O C, after installation and only when the cable is in a fixed position
The smallest. Bending radius: the outer diameter of the single-core cable is 20 x
The outer diameter of 15 multi-core cables is CE, RoHS, KEMA and other requirements
