Copper Conductor Mica Tape PVC/PE Insulated Fire Resistant Cable Single Core IEC60332 Fire Proof Cable
Fire Proof Cable
Rated Voltage: 300/500V 450/750V 0.6/1KV
Model: FR FireAlarm
Range of Nominal cross section
1 core: 1.5 mm2 ~ 300 mm2 Multi core: 0.75 mm2 ~ 35 mm2
Applications
Used for tall building, Hospital, Theatre, Power station, Metro Tunnel or Petrochemical Industry or other special place required for low smoke , zero halogen clean and safe cable.
These cables are installed to supply power to building essential services including fire alarms,
sprinkler control system, emergency and evacuation lighting and smoke control systems,
such as high rise buildings and apartments, airports, shopping centres, cinemas and road and rail tunnels
Constructions
Conductor: Class 1/2 Plain annealed copper wires, solid or stranded, with mica tape wound
Insulation: XLPE or LSZH compound
Sheath: Non or LSZH compound for multicores
Core color: red, black, blue, white for active core, green/yellow for earth core, orange or red or black for sheath
Max. Operating Temperature :100 meters per roll or wooden drum or as per requirement
Production Capacity :20 kilometer/ day
MOQ : 5000 meters for small size, 1000 meters for big size
Standards
International: IEC 60502, IEC 60227 IEC 60331, IEC 601034
China: GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001
Other standards such as BS,DIN and ICEA upon request
Technical data
Rated voltage: 300/500 V 450/750V
Max. Conductor Temp. in normal use: 90℃
Min. Bending Radius: 6 x cable O.D
Certificates
CE, RoHS, CCC, KEMA and more others at request
Fire Resistant Cables (Single-Core)
• Rated voltage: 450/750V, 600/1000V
• Construction: Bare stranded or solid copper conductor / Mineral ceramic (Mica/Glass) fire resistant tape / LSOH insulation
• Range: 0.5mm² – 400mm²
• Application: For fixed wiring / Essential safety circuits where the cable is protected by trunk or conduit
300/500V Mica+XLPE Insulated, LSZH Sheathed Power Cables (2-4 cores)
600/1000V Mica+XLPE Insulated, LSZH Sheathed Power Cables (2-4 cores)
300/500V SR Insulated Control Cables (2-4 Cores)
300/500V SR Insulated & Overall Screened Control Cables (2-4 Cores & Multicores)
300/500V Mica+SR Insulated & Overall Screened Control Cables (2-4 Cores & Multicores)
450/750V SR Insulated Control Cables (2-5 Cores)
450/750V SR Insulated & Overall Screened Control Cables (2-4 Cores & Multicores)
600/1000V SR Insulated Flexibles Control Cables
FAQ
1. Shipping: By sea or air due to heavy weight. Samples will be send by DHL, Fedex. etc
2. Payment: We accept T/T, L/C , just choose what you like
3. Delivery time: Generally 15~25 working days upon receipt deposit. According to the quantity.
4. MOQ: Generally our MOQ is 1000meters. samples below 20 centimeter can be provided freely.
