Industrial MYP Screen Rubber Sheathed Cable , Rubber Electrical Cable
Characteristics
1. Rated power-frequency voltage U0/U: 450/750V, 300/500V and 200/200V.
2. Maximum permitted operating temperature of conductor is 60°C.
3. Permitted lowest working temperature is -35°C.
4. Cables can be used at places contaminated by mineral oil and fuel oil.
Construction:
Conductor: Flexible Class 5 Copper Conductor
Insualtion: Rubber Sheath
Screen: Copper Wire or others
Sheath: Rubber Sheath
Implemented standard
1 For the non-spread combustion cable, implement GB12972
2 For the flame-retardant cable, implement MT818
3 For the special mining cable(with bigger cross-section and higher voltage),implement the enterprise standard.
Type and Name:
| Type | Description | Application |
| MC-0.38/0.66 | Rubber flexible cable for excavator | As the power connection used in the excavator |
| or similar equipment with rated voltage 0.38/0.66kV | ||
| MCP-0.38/0.66 | Shielded, rubber-sheathed flexible cable for excavator | As the power connection used in the excavator |
| or similar equipment with rated voltage 0.38/0.66kV | ||
| MCP-0.66/1.14 | Shielded, rubber flexible cable for excavator | As the power connection used in the excavator |
| or similar equipment with rated voltage 0.38/0.66kV | ||
| MCPJB-0.66/1.14 | Shielded ,monitoring and braiding reinforced type, | As the power connection used in the excavator |
| rubber flexible cable for excavator | or similar equipment with rated voltage 0.66/1.14kV, | |
| it can be dragged directly | ||
| MCPJR-0.66/1.14 | Shielded ,monitoring and braiding reinforced type, | As the power connection used in the excavator |
| rubber flexible cable for excavator | or similar equipment with rated voltage 0.66/1.14kV, | |
| it must be used in the protective chain panel | ||
| MCPT-0.66/1.14 | Metallic shielded rubber flexible cable for excavator | As the power connection used in the excavator |
| or similar equipment with rated voltage 0.66/1.14kV | ||
| MCP-1.9/3.3 | Shielded rubber flexible cable for excavator | As the power connection used in the excavator |
| or similar equipment with rated voltage 1.9/3.3kV | ||
| MCPT-1.9/3.3 | Metallic shielded rubber flexible cable for excavator | As the power connection used in the excavator |
| or similar equipment with rated voltage 1.9/3.3kV | ||
| MCPTJ-1.9/3.3 | Metallic shielded, monitoring type, rubber flexible cable for | As the power connection used in the excavator |
| excavator | or similar equipment with rated voltage 1.9/3.3kV | |
| MY-0.38/0.66 | Movable rubber flexible cable for mining | As the power connection used in the mining |
| machine with rated voltage 1.9/3.3kV | ||
| MYP-0.38/0.66 | Movable shield rubber flexible cable for mining | As the power connection used in the mining |
| machine with rated voltage 0.38/0.66kV | ||
| MYP-0.66/1.14 | Movable shield rubber flexible cable for mining | As the power connection used in the mining |
| machine with rated voltage 0.66/1.14kV | ||
| MYPJ-3.6/6 | Monitoring movable shield rubber flexible cable for mining | As the power connection used in the mining t |
| ransformer and similar equipment with rated voltage3.6/6kV | ||
| MYPTJ-3.6/6 | Metallic shielded monitoring type movable | As the power connection used in the mining |
| rubber flexible cable | transformer and similar equipment with rated voltage3.6/6kV | |
| MYP-3.6/6 | Movable shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
| the min. environment temperature is-20℃ | ||
| MYPT-3.6/6 | Movable metallic shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
| the min. environment temperature is-20℃ | ||
| MYPD-3.6/6 | Movable shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
| the min. environment temperature is-40℃ | ||
| MYPTD-3.6/6 | Movable metallic shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV |
| the min. environment temperature is-40℃ | ||
| MZ-0.3/0.5 | Driller cable for mining | As the power connection of driller with rated |
| voltage 0.3/0.5kV | ||
| MZP-0.3/0.5 | Driller shielded cable for mining | As the power connection of driller with rated |
| voltage 0.3/0.5kV | ||
| MYQ-0.3/0.5 | Movable light-type rubber flexible cable for mining | Lighting in the mine, as the power connection |
| of the interlock and control signals | ||
| used in the transport machine and equipment |
| CorexSize | Nominal Thickness | Overall diameter(mm) MY0.38/0.66 |
||||
| Phase | Grounding | Control | Insulation | Sheath | Min | Max |
| 3x16 | 1x16 | 3x4 | 1.5 | 5 | 35.8 | 38.6 |
| 3x25 | 1x16 | 3x4 | 2 | 5 | 39.7 | 42.9 |
| 3x35 | 1x16 | 3x4 | 2 | 5 | 43.1 | 46.3 |
| 3x50 | 1x25 | 3x4 | 2.2 | 5.3 | 48.5 | 51.8 |
| 3x70 | 1x35 | 3x6 | 2.2 | 5.8 | 55.1 | 58.8 |
| 3x95 | 1x50 | 3x6 | 2.4 | 6.4 | 62.4 | 66.1 |
| 3x120 | 1x50 | 3x10 | 2.6 | 6.9 | 68 | 72.5 |
| 3x150 | 1x70 | 3x10 | 2.6 | 7.3 | 74.5 | 79.5 |
| 3x185 | 1x70 | 3x10 | 2.8 | 7.5 | 80.7 | 86.1 |
| Core Type | Nominal Size | Min Insulation Resistance at 20℃(MΩ.km) | |
| No more than 0.66/1.14KV | 1.9/3.3KV | ||
| Phase Conducor or Asistant Conductor |
16 | 350 | 1150 |
| 25 | 300 | 980 | |
| 35 | 260 | 850 | |
| 50 | 230 | 740 | |
| 70 | 210 | 630 | |
| 95 | 200 | 550 | |
| 120 | 200 | 510 | |
| 150 | 180 | 450 | |
| 185 | 160 | 400 | |
| Control Conductor | 4.6.10 | 100 | 100 |
