Single Core 0.6KV / 1KV Low Smoke Halogen Free Mica Tape Power Cable

MOQ: 500M
Price: 0.1-99 USD/M
Standard Packaging: Wooden Iron Drum
Delivery Period: 10 working days
Payment Method: L/C, D/A, D/P, T/T
Supply Capacity: 5000 KM/Month
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
QINGDAO YICABLE CABLE
Certification
CE, IEC
Conductor:
Copper Conductor
Tape:
Mica Tape
Insulation:
XLPE
Wrapping Tape:
LSOH Bending Tape
Standards:
IEC60332,IEC60502
Insulation Color:
As Per IEC Requirement
Packing:
Steel Wooden Drum
Outer Sheath Color:
Orange
Highlight:

low smoke zero halogen wire

,

xlpe lszh cable

Product Description

Single Core 0.6/1KV Low Smoke Halogen Free Mica Tape Power Cable Shanghai Brand



Construction

1 Conductor: Compact stranded copper conductor, Cl.2 as per lEC60228

(11 MicaTape

③lnsulation:XLPE(cross-linked polyethylene) rated at 90°C

(1111 Filler

(5: Wrapping Tape: LSOH BendingTape

⑥Sheath:LSOH,black or other colors,as per lEC60332,60502-1





CodeDesignation

YJ:XLPEinsulation Y: LSOH sheath







Standards

lnternational: IEC60502. IEC60228, (lEC60332-3forFRcableonly) China: GB/T12706,(GB/T18380-3 for FR cable only)

Other standards such as BS, DIN and lCEAupon request







Technical data

Ratedvoltage: 0.6/ 1㎸

Maximum Conductor Temperature: under normal (90°C), emergency(130°C) or short circuit no more than5 s(250°C) conditions Min.AmbientTemp.-15°C,lnstallationTemp.0°C



Single Core 0.6KV / 1KV Low Smoke Halogen Free Mica Tape Power Cable 0
