Signal Building Low Smoke Zero Halogen Cable Single Core 300V 500V
Descriptions
Single-core non-sheathed cables with flexible conductor for internal wiring for a conductor of 90℃
Code designation: 60227 IEC 08 (International), BV-90 300/500V(China)
Constructions
① Conductor: Flexible copper conductor, comform to IEC 60228 class 1,2,5
② Insulation: LSZH PO
Applications
Used in the switch control, relay and instrumentation panels of power switchgear and for purposes such as
internal connectors in rectifier equipment, motor starters and controllers.
Standards
International: IEC 60227
China: GB/T 5023-2008
Other standards such as BS,DIN and ICEA upon request
Technical data
Rated voltage:300/500 V
Max. Conductor Temp. in normal use: 90℃
Min. Bending Radius: 6 x cable O.D
Certificates
CE, RoHS, CCC, KEMA and more others at request
Temperature range :
during installationi : +5 °C up to +70 °C
fixed installed : -30 °C up to +70 °C
at short circuit of max. 5 s : up to 150 °C
ambient temperature at storage : up to 40 °C
Nominal voltage : Uο/U = 300/500 V
Test voltage : 2000 V
Minimal inner bending radius : 4D for D < 8 mm
5D for 8 - 12 mm
6D for D > 12 mm
Samples:
1) We can make the samples according to customer’s samples or designs.
2) Our designer team can finish the samples timely, the exact sample delivery time depends on.
Payment Terms:
1) T/T, 30% T/T deposit before production, pay the balance before shipment.
Order and Mass Production:
1) We will send PROFORMA INVOICE to you when the order is confirmed.
2) We will start to have mass production when confirm our sample and 30% T/T deposit received.
3) Quality is under the control and supervision during the production.
4) Packing information will be confirmed before the production finished, If no special requirment, using our normal package.
Packaging & Shipping
Standard Packaging | suitable for long-distance shipment |
Normal cable factory length | one coil with 100 meter |
Cable Weight | Approx. 15kg/km ~500kg/km |
